Automatic Carton Box Folding Gluing Machine 120m/Min Pre Creasing

Ask Lasest Price
Brand Name :	PRINTYOUNG
Model Number :	PRY-2400
Certification :	CE
Price :
Payment Terms :	L/C, T/T
Supply Ability :	10 Set/Sets per Month
Delivery Time :	30 days

Add to Cart

Product Details
Company Profile

Automatic Carton Box Folding Gluing Machine 120m/Min Pre Creasing

Products Description

Feature

This model is of high configuration,left-right arms moving can be
adjusted by remote control, easy to operate and save labor
time.Very suitable for carton making factories

Feeding Section

* Shafts made of seamless steel pipe with thickness 20mm
* Paper fed by belt with high power vacuum suction control, making
feeding easy and stable
* Gluing and folding section
* Gluing automatically by pneumatic control
* Pre-creasing and forming creasing wheels on the folding section
makes the creasing line better,easy to be folded and free of
cracking
* Cardboard conveyed and folded by flat belt , smooth and stable
* Lateral moving adjusted motorized control ,easy and smooth
* Rectification and output section
* Rectification adjusted by eccentric bearings and stepless
speed-djustment device, free of fish tail
* Rectification feeding part can move laterally with any size,makes
the cartons formed well
* Automatic counting and stacking ,the cartons pushed out
automatically when reach the setup number

Applicability

* The machine suitable for 3 ply and 5 ply cardboard gluing
* Cardboard size:length 750mm-2400mm,width 300mm-1100mm
* Economic working speed:100-130m/min
* Core technology
* Carton forming quickly
* Paper feeding accurate under vacuum suction control
* Second creasing makes the creasing line formed well
* Carton joint glued well, meet standards, few waste.
* Double rectification structures are free of fish tail
* Accurate counting
* Stroke section makes the cartons formed well
* Output accurately and steadily
* Long service time
* Convey belts warranty:1 year
* Electric parts warranty: 1 year
* The main structure has lifetime warranty

Parts

* Motors are CHENGMING brand from Taiwan
* High power blower are SHENGHONG brand from Taiwan
* Stepless speed adjustment device form Shanghai
* Electromagnetic clutch and electromagnetic brake are YANDE brand
from Shanghai
* All the belts are SIEGLINE Brand from Germany
* Total power:10KW

Technical Parameters

PRY-2400 Automatic Carton Folding Gluing Machine
Model No.	PRY-2400
Max. Cardboard	2380*1100 mm
Mini. Cardboard	800*300 mm
Installation Area	14*3.2 m
Power Required	7.8 kw
Speed	0-120 m/min
Weight	6000 kg

Customer

Company Profile

Why Choose Us

Product packaging

Q1: Are you a manufacturer or a trading company?

A: Our shanghai office is mainly doing export. We have our own
factory in Wenzhou, Zhejiang Province.

Q2. What is the machine warranty?

A: One year. After the warranty, we still provide technical support
to buyer at low cost.

Q3. What is the production time while placing order?

A: Normally about 10-20 days.

Q4. What is the delivery time?

A: 15-30days after deposit.

Q5. Can your company handle shipping for customers?

A: Yes, just give us destination sea port or container yard.

Q6. Does the packing strong?

A: Yes. Adopts moisture-proof and shock-proof packaging which is
suitable for long-distance road transportation and various types of
weather conditions. A full set of maintenance and operation manuals
is included..

Q7. How about the machine installation and training ?

A: 1)We provide training in our factory for free; 2)We can send
technicians (engineers) to your factory for installation and
training. You shall pay the round trip air fare and accommodations,
plus each technician charges USD100/per day.

Q8. Do you have machines in stock?

A: For standard model, we have a large quantity in stock. For
special model, we need 20-30 days to produce it for you.

Q9. How can you assure the machines’ quality?

A: Each machine will be test running at least 24 hours before
delivery to assure the quality. And during the warranty, we will
give spare parts for free if machine has any problem.

Q10. Do you inspect machines or test running before packing?

A: Of course we do. We have QC department to debug the machine
before packing. If you want to use specific material to do the test
running, you need to pay for the cost of the material.

Q11. What’s the payment term?

A: T/T 30% in advance, the balance shall be paid before delivery.
We also accept payment by West Union or L/C at sight.

Q12. Do you accept factory visiting?

A: Warmly welcome for your visiting.

Q13. How many years are you in printing field?

A: Shanghai company is 12 years old, the factory is more than
20years.

Q14. How many clients do you have?

A: We have sold our machines to about 60 countries. We have agents
in South Africa, Morocco and Italy.
